5 inch 100w 4 ohm car audio speaker

  • HC130T-2-R8
  • HC
  • Product name: 5 inch full range speaker driver unit
  • Rate power: 45 Watt
  • Max power: 90 Watt
  • Sensitivity: 91±3dB
  • Impedance: 4/6/8Ω Provide customized services
  • Frequency: Fo~~20KHZ
  • Resonance frequency: 85hz±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 80*32*15mm
  • Size: Dia 129*63mm
Quantity:
trending products 5 inch loudspeaker 100w 4 ohm car audio speaker

Attribute
Value
1.1 Rate power
45 W
1.2 Max power
90 W
1.3 Sensitivity
91±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
8Ω±15%
1.5 Frequency
Fo~~20KHZ
1.6Resonance frequency
85hz±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ80*32*15mm
1.9 Weight
720g±8%
2.0 Size
Φ129*63Hmm
2.1voice coil & Material
Φ25.5mm Aluminum+ Φ20mm NdFeB silk tweeter + division electric capacity
2.2 Cone
Injection cone + matt black plating
