4 inch 30w 8ohm full rang speaker

  • HC102W-46-R8
  • HC
  • Product name: 4" 102mm full range 25w raw speaker
  • Rate power: 25Watt
  • Max power: 30Watt
  • Sensitivity: 92±3dB
  • Impedance: 4/8/16Ω Provide customized services
  • Frequency: Fo~~15KHZ
  • Resonance frequency: 120hz±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 70*32*10mm
  • Size: 102*102*41mm
Quantity:
4 inch 30w 8ohm audio car speaker full rang speaker driver for multimedia
Attribute
Value
1.1 Rate power
25 W
1.2 Max power
30 W
1.3 Sensitivity
92±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
8Ω±15%
1.5 Frequency
Fo~~15KHZ
1.6Resonance frequency
120hz±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ70*32*10mm
1.9 Weight
374g±8%
2.0 Size
102*102*41Hmm
2.1voice coil & Material
Φ19.45mm ASV+Cu
2.2 Cone
Paper cone with rubber edge
