52mm*16mm 18V 95dB IP65 waterproof buzzer

  • HPT5216-TP-18-2.0-250-R
  • HC
  • Rated Voltage (Vp-p): 18V
  • Operating Voltage (Vp-p): 3-60V
  • Resonant Frequency (Hz): 2000±500
  • Capacitance at120Hz (PF): 250000±30%
  • Sound Output at 10cm (dB): ≥95
  • Current Consumption (mA): ≤150
Quantity:
Loud sound 52mm*16mm 18V 95dB IP65 waterproof buzzer siren
Model
HPT5216-TP-18-2.0-250-R
Rated Voltage (Vp-p)
18
Operating Voltage (Vp-p)
3~60
Resonant Frequency (Hz)
2000±500
Current Consumption (mA)
≤150
Sound Output at 10cm (dB)
≥95
Capacitance at120Hz (PF)
250000±30%
Operating Temperature (℃)
-20~+95
Storage Temperature (℃)
-30~+105
Weight (g)
14
RoHs
Yes
