13MM*6MM 3V ac 75db piezoelectric transducer

  • HPT1360A-TO-03-4.0-12-7.6-R
  • HC
  • Product name: 13mm passive piezo transducer buzzer
  • Application: buzzer call system
  • Rated Voltage (Vp-p): 3 V
  • Operating Voltage (Vp-p): 1-30 V
  • Resonant Frequency (Hz): 4000±500
  • Sound Output at 10cm (dB): ≥75
  • Current Consumption (mA): ≤3
  • Capacitance at120Hz (PF): 12000±30%
Quantity:
13MM*6MM 3V ac 75db bell alarm buzzer
Model
HPT1360A-TO-03-4.0-12-7.6-R
Rated Voltage (Vp-p)
3
Operating Voltage (Vp-p)
1~30
Resonant Frequency (Hz)
4000±500
Current Consumption (mA)
≤3
Sound Output at 10cm (dB)
≥75
Capacitance at120Hz (PF)
12000±30%
Operating Temperature (℃)
-20~+70
Storage Temperature (℃)
-30~+80
Weight (g)
0.8
RoHs
Yes
