4 inch 4 ohm 5W raw speaker drivers

  • HC102W-43-R4
  • HC
  • Product name: 4" full range speaker driver unit
  • Size: 102*102*37H mm
  • Rate power: 3W
  • Max power: 4W
  • Sensitivity: 96±3dB
  • Impedance: 4,8,16Ω Provide customized services
  • Frequency: Fo~~10KHZ
  • Resonance frequency: 150±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 60*32*10MM
Quantity:
4 inch 4ohm 4W best loudspeaker components square midrange paper cone speaker drivers high end loudspeaker unit china speaker manufacturer
Attribute
Value
1.1 Rate power
3W
1.2 Max power
4W
1.3 Sensitivity
96±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
4Ω±15%
1.5 Frequency
Fo~~10KHZ
1.6Resonance frequency
150±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ60*32*10MM
1.9 Weight
225g±8%
2.0 Size
Φ102*102*37H mm
2.1voice coil & Material
Φ14.28mm ASV+Cu
2.2 Cone
Paper  cone
