3 inch 77mm 5w 8ohm speaker driver

  • HC66W-32F-R8
  • HC
  • Product name: 3 inch mid range neodymium magnet raw speaker
  • Rate power: 5Watt
  • Max power: 6Watt
  • Sensitivity: 98±3dB
  • Impedance: 8 ohm Provide customized services
  • Frequency: Fo~~10KHZ
  • Resonance frequency: 400 hz±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 32*18*4mm NdFeB
  • Size: Dia 76*22.5Hmm
Quantity:
china 3 inch 77mm 5w 8ohm outer-magnet round speaker driver unit

Attribute
Value
1.1 Rate power
5 W
1.2 Max power
6 W
1.3 Sensitivity
98±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
8Ω±15%
1.5 Frequency
Fo~~10KHZ
1.6Resonance frequency
400hz±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ32*18*4mm NdFeB
1.9 Weight
60g±8%
2.0 Size
76*22.5Hmm
2.1voice coil & Material
Φ13.28mm KSV+Cu
2.2 Cone
PET
