102x102mm 8ohm 5w waterproof speaker

  • HC102W-8F-R8
  • HC
  • Product name: IP67 high end raw speaker driver
  • Rate power: 3 Watt
  • Max power: 5 Watt
  • Sensitivity: 98±3dB
  • Impedance: 8 ohm Provide customized services
  • Frequency: Fo~~5KHZ
  • Resonance frequency: 900 hz±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 45*22*10MM
  • Size: 102*102*38.5Hmm
Quantity:
wholesale 102x102mm waterproof speaker 4 inch 8 ohm 5w square speaker unit IP67
Attribute
Value
1.1 Rate power
3 W
1.2 Max power
5 W
1.3 Sensitivity
98±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
8Ω±15%
1.5 Frequency
Fo~~5KHZ
1.6Resonance frequency
900hz±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ45*22*10MM
1.9 Weight
185g±8%
2.0 Size
102*102*38.5Hmm
2.1voice coil & Material
Φ19.45mm ASV+Cu
2.2 Cone
PET
