102mm loudspeaker driver unit

  • HC102W-18-R4
  • HC
  • Product name: 4 inch auto speaker car audio speaker
  • Rate power: 5 Watt
  • Max power: 10 Watt
  • Sensitivity: 95±3dB
  • Impedance: 4/8/16Ω Provide customized services
  • Frequency: Fo~~10KHZ
  • Resonance frequency: 170±20%
  • Distortion rate: ≤5%
  • Magnet size: Dia 55*25*8mm
  • Size: 131*102*33Hmm
Quantity:
Best 4 inch 4ohm 10W car audio speaker 102mm loudspeaker driver unit
Attribute
Value
1.1 Rate power
5 W
1.2 Max power
10 W
1.3 Sensitivity
95±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
1.4 Impedance
4Ω±15%
1.5 Frequency
Fo~~10KHZ
1.6Resonance frequency
170±20%
1.7 Distortion rate
≤5%
1.8 Magnet size
Φ55*Φ25*8mm
1.9 Weight
176g±8%
2.0 Size
131*102*33Hmm
2.1voice coil & Material
Φ14.28mm ASV+Cu
2.2 Cone
Paper cone with cloth edge
