24mm*10mm DC 5v 12v 24v quiz buzzer

  • HPB2410-1-TB-12-3.5-15.0-R
  • HC
  • Product name: 24mm low price alarm piezoelectric buzzer
  • Application: Household appliance boot tone, shutdown prompt tone and alarm
  • Rated Voltage (VDC): 12V
  • Operating Voltage (VDC): 3-24V
  • Resonant Frequency (Hz): 3500±500
  • Sound Output at 10cm (dB): ≥90
  • Rated Current (mA): ≤15
  • Operating Temperature (℃): -20~+70
  • Storage Temperature (℃): -30~+80
Quantity:
24mm*10mm DC 5v 12v 24v pin type piezoelectric ceramic alarm buzzer quiz buzzer
Model
HPB2410-1-TB-12-3.5-15.0-R
Rated Voltage (VDC)
12
Operating Voltage (VDC)
3~24
Resonant Frequency (Hz)
3500±500
Rated Current (mA)
≤15
Sound Output at 10cm (dB)
≥90
Operating Temperature (℃)
-20~+70
Storage Temperature (℃)
-30~+80
Weight (g)
2.8
RoHs
Yes
